BACnet Device Profile BACnet Advanced Application Controller (B-AAC) Inputs 16 Universal Inputs (10-bit), supporting: 0-5 VDC 0-10 VDC 10 kΩ Thermistor Dry Contact (using 10 kΩ Thermistor jumper setting) 4-20 mA Device Addressing Set via DIP switches and jumpers, or software setup Connectors Removable screw-type terminal connectors Wiring Class Class 2 Power 24 VAC 50/60 Hz @ 8 VA Technology 16-bit processor 1 MB (8 megabit) Flash memory 128 KB SRAM memory for database Communications Ports RS-485 NET1: BACnet MS/TP up to 76800 bps, max 99 devices per port RS-485 NET2: Delta LINKnet up tp 76800 bps, max 4 devices on LINKnet, with no more than 2 DFM devices Ambient 32° to 131°F (0° to 55°C) 10 to 90% RH (non-condensing) Dimensions 8½ x 4¼ x 115/16 in. (21.8 x 10.7 x 4.9 cm) with housing Weight 0.80 lb. (360 g) with housing Compliance CE FCC Listings C-UL Listed UL 916 Listed UL 864 Listed for UL 864 product numbers BTL Listed
