MS Input/Output Modules

Hàng hot: | Lượt xem: 2065

Danh mục : Bms Controller
Nhãn hiệu : Johnson Controls

A range of Input/Output modules compatible with Metasys.

Mô tả Giá thành viên Mua hàng
MS-IOM1711-0 MS-IOM1711-0 FINAL (Input Module, 4 Binary Inputs) Đăng nhập Đăng nhập
MS-IOM2711-0 MS-IOM2711-0 FINAL (Input/Output Module, 2 Universal Inputs, 2 Relay Outputs, 2 Universal Outputs.) Đăng nhập Đăng nhập
MS-IOM2721-0 MS-IOM2721-0 IN/OUTPUT (Input Output Module with 8 Universal Inputs and 2 Analog Outputs, 24 VAC) Đăng nhập Đăng nhập
MS-IOM2723-0 10-Point IOM with 8 UI, 2 AO, FC and SA Bus Support (The Input/Output Expansion Module has 10 Input/Output (I/O) points (8 UI, 2 AO) and is BTL-listed and certified at Protocol Revision 15.) Đăng nhập Đăng nhập
MS-IOM3711-0 MS-IOM3711-0 FINAL (Input/Output Module, 4 Universal Inputs, 4 Relay Outputs, 4 Universal Outputs.) Đăng nhập Đăng nhập
MS-IOM3721-0 MS-IOM3721-0 IN/PUT (Input Output Module with 16 Binary Inputs, 24 VAC) Đăng nhập Đăng nhập
MS-IOM3723-0 16-Point IOM with 16 BI, FC and SA Bus Support (The Input/Output Expansion Module has 10 Input/Output (I/O) points (8 UI, 2 AO) and is BTL-listed and certified at Protocol Revision 15.) Đăng nhập Đăng nhập
MS-IOM3731-0 MS-IOM3731-0 INPUT/OUT (Input Output Module with 8 Binary Inputs and 8 Binary Outputs, 24 VAC) Đăng nhập Đăng nhập
MS-IOM3733-0 16-Point IOM with 8 BI, 8 BO, FC and SA Bus Support (The Input/Output Expansion Module has 16 Input/Output (I/O) points (8 BI, 8 BO) and is BTL-listed and certified at Protocol Revision 15.) Đăng nhập Đăng nhập
MS-IOM4711-0 IOM4711 IOM 17 POINT (Input/Output Module, 6 Universal Inputs, 2 Binary Inputs, 3 Binary Outputs, 4 Configurable Outputs, 2 Analog Outputs) Đăng nhập Đăng nhập

Features

Ability to Reside on the FC Bus or SA Bus — Provides application flexibility.

Standard BACnet Protocol — Provides interoperability with other Building Automatcion System (BAS) products that use the widely accepted BACnet standard.

BACnet Testing Laboratories (BTL) Listed and Certified — Ensures interoperability with other BTL-listed devices. BTL is a third-party agency, which validates that BAS vendor products meet the BACnet industrystandard protocol.

Standard Hardware and Software Platform — Uses a common hardware design throughout the family line to support standardized wiring practices and installation workflows; also uses a common software design to support use of a single tool for control applications, commissioning, and troubleshooting to minimize technical training.

Universal Inputs and Configurable Outputs — Allows multiple signal options to provide input/output flexibility.

32-bit Microprocessor — Ensures optimum performance and meets industry specifications.

BACnet Automatic Discovery — Supports easy controller integration into a Metasys BAS.

Pluggable Communications Bus and Supply Power Terminal Blocks — Expedites installation and roubleshooting.

Wireless Connectivity through the ZFR1800 Series or the WNC1800/ZFR182x Pro Series Wireless Field Bus Systems in MS/TP Controllers — Enables wireless mesh connectivity to supervisory controllers, facilitating easy initial location and relocation.

Bluetooth® Wireless Commissioning — Provides an easy-to-use connection to the configuration and commissioning tool.

End-of-Line (EOL) Switch in MS/TP Field Controllers — Enables field controllers to be terminating devices on the communications bus

Ordering Information

FEC/FAC Controllers MS-DIS1710-0 - Building SparePart

1 IOM European Catalog Page
2 IOM3723
3 IOM2723
4 IOM3733
5 IOM17 & 2711
6 IOM2721
7 IOM3711
8 IOM3721
9 IOM3731
10 IOM47
